CHIMP CSP400 Water Pump
CHIMP CSP400 Water Pump - Image 2
CHIMP CSP400 Water Pump - Image 3
CHIMP CSP400 Water Pump - Image 4

CHIMP CSP400 Water Pump

Pump Installation & Application

  • Quickly and efficiently drain pools, ponds, and flooded basements.

  • Float switch controls the pump on and off automatically.

  • High-quality bearing, seals, and stainless steel motor shaft with special treatment ensure long lifetime.

  • Low-consumption electric motor with overload protection ensures safe operation.

Categories: , Tag: Brand:
MODEL: CHIMP CSP400 Submersible Water Pump

01 – APPEARANCE

  1. Every detail part is carefully selected, burnished, polished, and cleaned.
  2. Automatic winding, more precise.
  3. Automatic spray paint, oven drying, strict inspection.

02 – QUALITY

  1. Strictly control the quality of the parts, make sure no error.
  2. 100% coiling testing to make sure each coil is energized and at high-voltage condition.
  3. 100% testing system for motor/complete set pump, quality assurance (adopt advanced pump testing equipment to test the pump performance).

03 – SERVICE

  1. With more than 20 years’ experience of production and sales.
  2. Professional technical team and sales team.
  3. 1-year warranty with technology support.
Specification:
Item Value
Model CSP400
Voltage 240
Power (kW) 0.4
Power (HP) 0.5
Max. Pump Rate (L/H) 7.3
Max. Height (m) 7.5
Max. Depth (m) 7
Max Grain Size (mm) 5
Dia of Pipe  1 – 1 1/2″
GW (kg) 15.8
